Mouting type：Horizontal
Power：3.7KW
Reduction ratio range：1:3~1:60
Brake：Available
Motor temperature rise：During rated operation, the winding temperature rise is measured by resistance method to be below 75K
Motor noise ：≤ 50dB
Insulation level：Class E (120 ° C)
Environmental temperature：0 ° C~+40 ° C
Operating humidity ：below 85% (non condensing state)
