Mouting type：Horizontal
Power ：1.5KW
Reduction ratio range：1:3~1:200
Brake：Available
Motor temperature rise：During rated operation, the winding temperature rise is measured by resistance method to be below 75K
Motor noise：≤ 50dB
Insulation level ：Class E (120 ° C)
Environmental temperature ：0 ° C~+40 ° C
Operating humidity：below 85% (non condensing state)
